DEYE 5KW HYBRID INVERTER, Single Phase 2 MPPT, SUN-5K-SG04LP1-AU
DEYE 5KW HYBRID INVERTER, Single Phase 2 MPPT, SUN-5K-SG04LP1-AU
Couldn't load pickup availability
- The DEYE 4th generation Hybrid Inverter. A multi functional inverter, combining functions of smart inverter, solar charger and battery charger, and with portable size. Support remote assist and upgrade by OTA. Easy install, easy maintenance. Smart APP/ platform enables user to monitor the solar system everywhere.
10 years full local warranty
2 mppt controller built in
Specification:
Battery Type: Lead-acid or Li-lon Battery Voltage Range (V): 40~60V
Max.Charging Current (A): 120A Max.Discharging Current (A): 120A
Charging Curve: 3 Stages/Equalization External Temperature Sensor: Yes
Charging Strategy for Li-Ion Battery: Self-adaption to BMS
PV String Input Data Max.DC Input Power (W): 6500W
PV Input Voltage (V): 370V(100V~500V) MPPT Range (V): 125V-425V
Start-up Voltage (V): 125V PV Input Current (A): 13A+13A
Max. PV ISC (A): 19.5A+19.5A No.of MPPT Trackers: 2
No.of Strings Per MPPT Tracker: 1+1
AC Output Data Rated AC Output and UPS Power (W): 5000W
Max AC Output Active Power (W): 5000W
Peak Power(off grid): 2 times of rated power, 10 S
AC Output Rated Current(A): 21.7A Max.AC Current(A): 21.7A
Max Continuous AC Passthrough(A): 35A
Output Frequency and Voltage: 50/60Hz; L/N/PE 220/230Vac
Grid Type: Single Phase
Current Harmonic Distortion: THD<3% DC Current Injection: <0.5% in
Grid Regulation: AS/NZS4777.2 Communication with BMS: RS485, CAN
Cabinet Size (WxHxD mm): 330×433×238 (Excluding Connectors and Brackets)
